DAC8413FPZ

Quad, 12-Bit DAC, Voltage Output, Readback, –0.3 V, +33.0 V, Unipolar or Bipolar Operation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $11.50~15.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $11.50~15.00

PartNumber:: DAC8413FPZ

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. doris's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-13

From Other Seller

Part Number:DAC8413FPZ
US $11.50 - 15.00
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The DAC8413FPZ is a quad, 12-bit voltage output DAC with readback capability. Built using a complementary BiCMOS process, these monolithic DACs offer the user very high package density. Output voltage swing is set by the two reference inputs VREFH and VREFL. By setting the VREFL input to 0 V and VREFH to a positive voltage, the DAC will provide a unipolar positive output range. A similar configuration with VREFH at 0 V and VREFL at a negative voltage will provide a unipolar negative output range. Bipolar output of the DAC8413FPZ is configured by connecting both VREFH and VREFL to nonzero voltages. This method of setting output voltage range has advantages over other bipolar offsetting methods because it is not dependent on internal and external resistors with different temperature coefficients.

Parametrics

DAC8413FPZ absolute maximum ratings: (1)VSS to VDD: –0.3 V, +33.0 V; (2)VSS to VLOGIC: –0.3 V, +33.0 V; (3)VLOGIC to DGND: –0.3 V, +7.0 V; (4)VSS to VREFL: –0.3 V, +VSS–2.0 V; (5)VREFH to VDD: +2.0 V, +33.0 V; (6)VREFH to VREFL: +2.0 V, VSS–VDD; (7)Current into Any Pin 4: ±15 mA; (8)Digital Input Voltage to DGND: –0.3 V, VLOGIC +0.3 V; (9)Digital Output Voltage to DGND: –0.3 V, +7.0 V; (10)Operating Temperature Range: –40℃ to +85℃; (11)Dice Junction Temperature: +150℃; (12)Storage Temperature: –65℃ to +150℃; (13)Power Dissipation Package: 1000 mW; (14)Lead Temperature (Soldering, 60 sec): +300℃.

Features

DAC8413FPZ features: (1)+5 V to ±15 V Operation; (2)Unipolar or Bipolar Operation; (3)True Voltage Output; (4)Double-Buffered Inputs; (5)Reset to Min; (6)Fast Bus Access Time; (7)Readback.
