SI7661CJ+

momolithic charge pump voltage inverter, DIP, -4.5V to -20V, cascaded voltage multiplication

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.55~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.55~0.80

PartNumber:: SI7661CJ+

Brand:: Maxim Integrated Products - Maxim | Pack: DIP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. doris's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-05

From Other Seller

Part Number:SI7661CJ+
US $0.55 - 0.80
SIL9185ACTU

US $2.30 - 5.00 / Piece
(0) Remove
AT45DB161B-TU

US $1.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SI7661CJ+ is a momolithic charge pump voltage inverter that will convert a positive voltrage in the range of 4.5V to 20V to the correspondng negative voltage of -4.5V to -20V. The SI7661CJ+ provides performance far superior to previous implementations of charge pump voltage inverters by combining low quiescent current with high efficiency. The SI7661CJ+ has an osicllator, control circuitry, and a 4 power MOS switches on-chip, with the only required external components being two low cost capacitors. The applications of the SI7661CJ+ include inexpensive negative supplies, data acquisition systems, up to -20V for Op Amps, and other linerat circuits, supply splitter, VOUT=VS/2 and RS-232 power supplies.

Parametrics

SI7661CJ+ absolute maximum ratings: (1)V+ to GND: -0.3V, +22V; (2)osicllator input to GND: -0.3V, V++0.3; (3)power dissipation: 300mW; (4)operating temperature range: 0 to 70℃; (5)storage temperature: -65 to 160℃; (6)lead temeprature (soldering, 10sec): 300℃.

Features

SI7661CJ+ features: (1)4.5V to 20V supply to -4.5V to -20V output; (2)cascaded voltage multiplication; (3)99.7% typical open circuit conversion efficiency; (4)requires only 2 external capacitors; (5)pin compatible with the ICL7660.
