Product Summary

The 2N7002LT1G is a Small Signal MOSFET.

Parametrics

2N7002LT1G absolute maximum ratings: (1)Drain.Source Voltage, VDSS: 60 Vdc; (2)Drain.Gate Voltage (RGS = 1.0 MΩ), VDGR: 60 Vdc; (3)Drain Current, ID: ±115mAdc when Continuous TC = 25℃; ±75mAdc when Continuous TC = 100℃; IDM: ±800mAdc when Pulsed; (4)Gate Source Voltage,Continuous, VGS: ±20Vdc; Non.repetitive (tp ≤50μs), VGSM: ±40Vpk.

Features

2N7002LT1G features: (1)Pb-Free Packages are Available.

Diagrams

2N7002LT1G circuit
