EL2244CS

low-Power, 120MHz, Unity-Gain Stable Op Amp, SOP, ±10V, 40mA, Low supply current

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.52~0.70 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.52~0.70

PartNumber:: EL2244CS

Brand:: Elantec Semiconductor - Intersil | Pack: SOP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. doris's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-01

From Other Seller

Part Number:EL2244CS
US $0.52 - 0.70
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The EL2244CS is a dual and quad low-Power 120MHz Unity-Gain Stable Op Amp. The EL2244CS is unity-gain stable and features a 325V/μs slew rate and 120MHz gain-bandwidth product while requiring only 5.2mA of supply current per amplifier. The applications of the EL2244CS include Video amplifiers, Single-supply amplifiers, Active filters/integrators, High speed signal processing, ADC/DAC buffers, Pulse/RF amplifiers, Pin diode receivers, Log amplifiers.

Parametrics

EL2244CS absolute maximum ratings: (1)Supply Voltage (VS):±18V or 36V; (2)Input Voltage (VIN): ±VS; (3)Differential Input Voltage (dVIN): ±10V; (4)Continuous Output Current: 40mA; (5)Operating Temperature Range (TA): -40 to +85℃; (6)Operating Junction Temperature (TJ): +150℃; (7)Storage Temperature (TST): -65 to +150℃.

Features

EL2244CS features: (1)120MHz gain-bandwidth product; (2)Unity-gain stable; (3)Low supply current (per amplifier)- 5.2mA at VS = ±15V; (4)Wide supply range - 2.5V to 36V; (5)High slew rate - 325V/μs; (6)Fast settling - 80ns to 0.1% for a 10V step; (7)Low differential gain - 0.04% at AV = +2, RL = 150ΩLow differential phase - 0.15Ω at AV = +2, RL = 150ΩWide output voltage swing - ±3.6V with VS = ±15V, RL = 1kΩLow cost, enhanced replacement; (8)Pb-Free available (RoHS compliant).
